KA-B6
Ren Thang Machine
The KA-B6 combines the automated conveyorized lead cutting of the KA-66 with a synchronized motorized copper brush cleaning station. Boards are trimmed and immediately brushed to remove residual solder dross and loose lead fragments in a single pass, guaranteeing pristine PCBA cleanliness.
Processing & Feature Tags
ENGINEERING SPECIFICATIONS
Machine Specifications & Performance
Processing Capacity 速度 0 ~ 3 M/min 無段調整 (約 600 ~ 1,200 片/小時)
Power / Air Supply 220V AC, 50/60Hz (主軸 3/4 HP, 4,500 RPM + 銅刷 1/5 HP, 600 RPM)
Standard Tolerance 最低腳高 > 1.0mm (可調)
Dimensions (L×W×H) 1160(L) × 730(W) × 800(H) mm
Net Weight 200 kg
Catalog Page & Status
P.15 (Catalog_0015) • 在產 (Active)
【Key Machine Features & Advantages】
- All-in-one automatic PCB lead trimmer and bottom brush cleaning machine, engineered for inline post-wave-soldering finishing.
- Dual integrated processes: high-speed circular blade lead cutting followed immediately by a 600 RPM copper brush to sweep away solder balls, flux residue, and burrs.
- Flexible PCB envelope: accommodates board widths from 10 to 280 mm, max. PCB size 500 × 280 mm, and thickness from 0.8 to 2.5 mm.
- Comprehensive anti-warping protection: standard equipment includes bakelite hold-down bars/frames (4 sets) and bottom support thimble wheel (1 set) to prevent PCB deflection.
- Powerful drive system: 3/4 HP spindle motor (4,500 RPM) and 1/5 HP copper brush motor (600 RPM) with stepless conveyor speed from 0 to 3 m/min.
- Fully equipped standard accessories: includes Ø250mm copper brush (1 unit), warp-proof bakelite bar/frames, anti-sagging thimble wheel, and maintenance toolkit.
- Modular in-line expansion options:
- • KAB6-IN Inlet Conveyor: docks directly with wave soldering machines to eliminate manual board loading.
- • KAB6-OU Outlet Conveyor: automatically transfers finished boards to secondary soldering or assembly conveyors.
- • KAB6-F Elevation Frame: customized stand height for seamless horizontal alignment with upstream/downstream lines.
- Tooling options: supports NK-200 (8") and NK-250 (10") micro-grain tungsten carbide circular blades, and BK-250 (Ø250mm) replacement copper brushes.
【Revision Notes】 標配Ø250銅刷、防彎電木壓台與頂針輪；可選購KAB6-IN/OU軌道、KAB6-F客製台架、鎢鋼刀NK-200/250。
Lead Forming & Geometric Parameter Specifications
Unit: mm / Custom tooling available Dimension & Bending Schematic KA-B6
Callouts match specifications in the table (Click image to enlarge)
| Code | Parameter | Standard Value / Range | Engineering Notes |
|---|---|---|---|
| PCB_RANGE | Applicable PCB Width | 10 ~ 280 mm (最大尺寸 500 × 280 mm) | Dual-track stepless knobs to open and close the width |
| THICK_RANGE | Rail Thickness Range | 0.8 ~ 2.5 mm | Claw spring clip automatic clamping and conveying |
| SPINDLE_SPEC | Spindle HP & RPM | 3/4 HP / 4,500 RPM | High-speed and strong cutting without burrs |
| BRUSH_SPEC | Copper Brush HP & RPM | 1/5 HP / 600 RPM (直徑 Ø250mm) | Instantly removes tin bead residue and sticky leads from the bottom of the board |
| FEED_SPEED | Conveyor Feeding Speed | 0 ~ 3 M / 分鐘 (速度可調) | Can be adjusted simultaneously with the plug-in table and wave soldering furnace |
| MIN_LEAD_H | Min. Lead Height | > 1.0 mm (刻度指示可調) | Not recommended < 0.8mm to prevent damage to the PCB substrate |
| STD_ACCESS | Equipped Standard Accessories | Ø250銅刷 / 防上彎電木條壓台4組 / 防下彎頂針輪 / 工具 | Complete anti-board bending and cleaning mechanisms are included as standard |
| EXP_INLINE | Optional Inline Modules | KAB6-IN 入料軌道 / KAB6-OU 出料軌道 / KAB6-F 專用台架 | The front and back connection of the wave soldering furnace is consistent and fully automatic |
