RT-200UL

Axial Horizontal Component Feeder 220V

軸向臥式零件供料機220V

The RT-200UL is a 220V automated horizontal loose-component feeder utilizing gentle vibration and precision sorting tracks to supply loose axial resistors and diodes continuously. Operating standalone or docked to forming stations, it eliminates manual staging bottlenecks with high reliability.

Processing & Feature Tags

Taped Axial

Straight Cutting

M-Shape, 90 Degree Bend

Kink - Outward/Inward

Taped - Axial

Auto Feeder

Pneumatic Drive

ENGINEERING SPECIFICATIONS

Machine Specifications & Performance

Processing Capacity 詳見型錄 / 依工件規格而定

Power / Air Supply 110V/220V 50/60Hz

Standard Tolerance ±0.3mm

Dimensions (L×W×H) 參見圖面

Net Weight -

Catalog Page & Status

P.01 • 在產 (Active)

【Key Machine Features & Advantages】

Stable 220V/50-60Hz Motorized Vibratory Feed: Quiet, continuous, and jam-free component delivery.
Precision Mechanical Orienting Track: Automatically aligns loose axial resistors and diodes for seamless transfer.
High Automation Compatibility: Operates standalone or docks directly to diverse axial forming workstations.
Stepless Feeding Speed Regulation: Finely tunes supply pace to synchronize with downstream automated insertion.
Rugged Industrial Chassis: Built for heavy-duty production floors, eliminating manual component staging labor.
