RT-700
Ren Thang Machine
The RT-700 is an automatic tube component feeder featuring an inclined magazine that holds up to 20 tubes for extended unattended continuous production. Optical sensors automatically trigger empty tube ejection, seamlessly feeding power transistors into RT-500/600 formers or CF-series trimmers without jams.
Processing & Feature Tags
TUB
STK
TUB
SEN
Auto Feeder
ENGINEERING SPECIFICATIONS
Machine Specifications & Performance
Processing Capacity 一次裝填 20 管 (Load 20 tubes at the same time)
Power / Air Supply 110V/60Hz ; 220V/50Hz
Standard Tolerance ±0.3mm
Dimensions (L×W×H) 980(L) x 550(W) x 1700(H) mm
Net Weight 29 kgs
Catalog Page & Status
P.11 (Catalog_0011) • 在產 (Active)
【Key Machine Features & Advantages】
- Automatic tube component feeder designed to replace manual hand-feeding, eliminating labor turnover and loading bottlenecks.
- Inclined magazine holds up to 20 component tubes simultaneously, enabling extended unattended continuous feeding.
- Equipped with high-precision optical sensors that automatically detect part movement and trigger empty tube ejection.
- Smooth and reliable feeding action eliminates part jams and prevents lead deformation or damage to power transistors.
- Wide host compatibility: links with RT-500 and RT-600 power transistor formers to substantially boost machine utilization.
- Extendable to link with CF-360/CF-360LX radial lead cutters and YF-900 transistor heatsink assembly machines.
- Heavy-duty ergonomic stand (height 1,700 mm) with casters for flexible production line positioning and seamless docking.
【Revision Notes】 一次填裝 20 管；配備光纖感應自動退換管機構；可無縫串接 RT-500、RT-600、CF-360、CF-360LX、YF-900。
Lead Forming & Geometric Parameter Specifications
Unit: mm / Custom tooling available Dimension & Bending Schematic RT-700
Callouts match specifications in the table (Click image to enlarge)
| Code | Parameter | Standard Value / Range | Engineering Notes |
|---|---|---|---|
| MAG_CAP | Magazine Capacity | 20 管 (Tubes) | Fill 20 tubes of electronic parts at one time, greatly extending the unattended replenishment cycle |
| SENSOR_TYPE | Sensor Mechanism | 高精度光纖自動感應 (Optical Sensor) | Automatically sense the material is in place, automatically withdraw and change tubes |
| COMPAT_HOST | Compatible Host Machines | RT-500, RT-600, CF-360, CF-360LX, YF-900 | Support power crystal molding machine, capacitor cutting machine and crystal heat sink assembly machine |
| APPLY_PKG | Applicable Packages | TO-220, TO-247, TO-263, TOP-3 等各型管裝件 | Support multiple specifications of standard material tubes |
